Description
The AS-223 DEA FBI Protocol Ballistic Helmet solution has been designed and developed specifically to meet the stringent requirements of the DEA / FBI and VPAM 3 test protocol within an ACH geometry. Designed to protect the most demanding users with reduced Trauma / Back-Face Deformation this custom designed helmet provides proven levels of performance and is available in regular, mid and high-cut shells, in both bolted and boltless configurations.
| SHAPE/DESIGN | U.S. Army ACH Geometry |
| SHELL CONSTRUCTION | Proprietary blend of Aramid and Composite Materials |
| BALLISTIC PROTECTION | German’s VPAM 3 Specification; U.S. DEA/FBI 2024 specifications; NIJ level IIIA 0108.01/0106.01 |
| FRAGMENTS PROTECTION | 17 grain V50 > 2100 f/s (640 m/s) |
| 9MM BFD/TRAUMA | Avg <8mm when tested to DOJ/DEA extended Protocol |
| ENVIRONMENTAL / MECHANICAL PROTECTION / DESIGN | Blunt Impact, Compression Resistance and Dynamic Strength in accordance with DOJ/DEA 2019 specifications |
| CERTIFICATION | From the German Lab of Mellrichstadt and from NTS, an NIJ certified laboratory |
| AVAILABLE SHELL SIZES | Medium / Large / X-Large |
| EXTREME TESTING CONDITIONS | Performs under temperature between 160 °F (71°C) and -60°F (-51°C); Performs after 3 hours sea water immersion |
| CONFIGURATION | 100% Boltless (Durability Verified) |
| SHELL THICKNESS | 0.35” (±0.1″) / 9 mm (±2.5mm) |
| FINISHED HELMET NOMINAL WEIGHT | Medium 1.5 kg (3.3 lbs); Large 1.54 kg (3.4 lbs); X-Large 1.64 kg (3.6 lbs) |
| FULLY LOADED HIGH-CUT NOMINAL WEIGHT | Medium 1.54 kg (3.4 lbs); Large 1.63 kg (3.6 lbs); X-Large 1.73 kg (3.8 lbs) |
Ballistic Performance
- DEA/FBI Specs (2024)
- NIJ Level IIIA
- Fragmentation Protection
- BFD / Trauma
- German VPAM 3 Specs
Environmental Performance
- Blunt Impact
- Compression Resistance
- Dynamic strength
- Advanced Boltless Adhesive System
Compatibility & Add-ons
- Universal side-rails
- NVG Mount
- Operational Loop System
- Counterweight
- Camouflage Cover
- Strap Extenders
- Visor / Goggles
- Communications / Ear Protection
- Gas Mask
